LKG RECP, 20A 120/208V, L21-20R by Hubbell Wiring Device-Kellems
- Part Number: L2120R
- UPC: 00783585192741
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Variations (7)
Product Overview
Locking Devices, Twist-Lock®, Female Receptacle, 20A 120/208V AC, L21-20R, Black
Specifications
Details
Electrical Category:
Electrical Distribution Equipment
Lugs Plugs And Connectors
Electrical Subcategory:
Receptacles
Receptacle
Amperage Rating:
20
Application:
Heavy Duty
Brand Name:
WIRING DEVICE-KELLEMS
Color:
Black
Connection:
Screw Terminals
Country Of Origin:
PR
Environmental Conditions:
Indoor Dry Unless Protected By Additional Means
Installation Link:
Line Drawing Link:
Material:
Thermoplastic
Mounting:
Screw Mount
NEMA Rating:
L21-20R
Number Of Poles:
4-Pole
Number Of Wires:
5-Wire Grounding
Order Minimum:
1.000 EA
Order Multiple:
1.000 EA
Phase:
Three Phase
Size:
Standard Sized Product
Spec Sheet:
Special Features:
Standard Product
Standard:
NEMA WD1 and WD5, UL 498
Sub Brand:
Twist-Lock Devices
Tech Drawing Link:
Type:
Single Receptacle
UNSPSC:
39121406
Voltage Rating:
3-Phase 120/208V AC kV
Wattage:
4,160
Weight:
.250 L
Wire Size:
#14 AWG to #12 AWG
Manufactured By:
Hubbell Wiring Device-Kellems
